Product Description
|
Aircraft
|
|
|
Takeoff weight
|
820g
|
|
Dimensions (including blades)
|
Folded: 210×104×85mm Unfolded: 430×517×85mm
|
|
Max takeoff altitude
|
5000m
|
|
Max flight time (no wind)
|
40min
|
|
Max flight distance (no wind)
|
24km
|
|
Max wind resistance
|
Level 7
|
|
Operating temperature
|
-10°C ~ 40°C
|
|
Operating frequency
|
2.400-2.4835GHz, 5.725-5.850GHz, 5.150-5.250GHz
|
|
GNSS
|
GPS
|
|
Gimbal (Lite)
|
|
|
Mechanical range
|
Pitch: -135°~45° Roll: -45°~45°
Yaw: -90°~90° Rotate: -400°~400° |
|
Stabilization
|
4-axis (horizontal/vertical/tilt/rotation shooting)
|
|
Max control speed (pitch)
|
30°/s
|
|
Gimbal (Lite Plus)
|
|
|
Mechanical range
|
Pitch: -135°~45° Roll: -45°~45°
Yaw: -90°~90° |
|
Stabilization
|
3-axis
|
|
Max control speed (pitch)
|
30°/s
|
|
Camera (Lite)
|
|
|
Sensor
|
CMOS: 1/1.28 inch
Effective pixels: 50M Pixel size: 1.22μm*1.22μm |
|
Lens
|
FOV: 85°
Equivalent focal length: 23mm Aperture: f/1.9 Focus range: 0.5m ~ ∞ Focus mode: PDAF+CDAF/MF |
|
Photo format
|
JPG / DNG / JPG+DNG
|
|
Photo resolution
|
50MP：8192x6144（4:3）
12.5MP（default）：4096x3072（4:3） 4K：3840x2160（16:9） |
|
Timelapse
|
Original image：3840*2160，JPG/DNG Video：4K P25
|
|
Camera (Lite Plus)
|
|
|
Sensor
|
CMOS: 1 inch Effective pixels: 20M
Pixel size: 2.4μm*2.4μm |
|
Lens
|
FOV: 82° Equivalent focal length: 29mm
Aperture: f/2.8 ~ f11 Focus range: 0.5m ~ ∞ Focus mode: CDAF/MF |
|
Photo format
|
JPG（10bit） / DNG(12bit) / JPG+DNG
|
|
Photo resolution
|
5472x3648 (3:2，default) 5472x3076 (16:9)
3840x2160 (16:9) |
|
Timelapse
|
Original image：5472*3076/3840*2160，JPG/DNG
Video：5.4K/4K P25 |
|
Remote controllor and image transmission
|
|
|
Max transmission distance
|
FCC：12km
|
|
Operating temperature
|
0°C ~40°C
|
|
Battery capacity
|
3930mAh
|
|
Max battery life
|
3.5h (when connected to a mobile phone)2.5h (when not connected to mobile phone)
|
|
Interface type
|
Type C
|
|
Aircraft battery
|
|
|
capacity
|
6175mAh
|
|
Battery Type
|
Li-Po 3S
|
|
Energy
|
68.7Wh
|
|
Single battery charging time
|
90min
|
|
App
|
|
|
Mobile App
|
Autel Sky
|
|
Mobile system required
|
iOS 12.0 and above Android 8.0 and above
|
Specification
|
item
|
value
|
|
Place of Origin
|
China
|
|
|
Guangdong
|
|
Brand Name
|
Evo Lite Plus
|
|
Model Number
|
Evo Lite Plus
|
|
Material
|
Plastic
|
|
Power
|
Battery
|
|
Function
|
Headless mode, Altitude Hold Mode, 3D View Mode, With Camera, With LED lights, with G-sensor, 3D flip, One Key Takeoff / Landing, APP Control, Voice control, With Remote Control, Foldable
|
|
Operator Skill Level
|
Beginner
|
|
Control Type
|
Remote Control
|
|
image transmission distance
|
10KM
|
|
Model Number
|
EVO Lite Plus
|
|
Camera
|
6K HD Camera
|
|
Charging time
|
90min
|
|
Battery
|
6175mAh
|
|
Flying time
|
40min
|
|
Image transmission
|
12km
|
|
Stabilization
|
4-axis
|
Packing & Delivery
| Product Code |
31879 |
|---|---|
| Category |
Drone |
